g229849

g229880

Figure52

1.Knob(reel-speedcontrol)

3.Indicatorarrow

2.Handle(backlaplever)

Note:Youcanincreaseordecreasethereel

speedtocompensateforturfconditions.

BacklappingtheReels

WARNING

Contactwiththereelsorothermovingparts

canresultinpersonalinjury.

•Keepyourhandsandclothingawayfrom

thereelsorothermovingparts.

•Neverattempttoturnthereelsbyhandor

footwhiletheengineisrunning.

1.Parkthemachineonalevelsurface,lowerthe

cuttingunits,shutofftheengine,andengage

theparkingbrake.

2.Tilttheoperator’sseatforwardandsupportit

withtheproprod(Figure53).

g229847

Figure53

3.Makeinitialreeltobedknifeadjustments

appropriateforhoningallthecuttingunitsthat

youarebacklapping;refertotheCuttingUnit

Operator'sManual.

4.RotatethebacklaplevertotheRposition

(Figure54).
