g234996

Figure17

1.CEproductionyeardecal3.Serialplate

2.CEmarkdecal

•ApplytheCEproductionyeardecalnexttotheCE

markdecal(Figure17).

BurnishingtheBrakes

NoPartsRequired

Procedure

Burnishthebrakes;refertoBurnishingtheBrakes

(page42).

ProductOverview

Controls

TractionPedal

Thetractionpedal(Figure18)has3functions:

tomakethemachinemoveforward,tomoveit

backward,andtostopthemachine.Pressthetop

ofthepedaltomoveforwardandthebottomofthe

pedaltomovebackwardortoassistinstoppingwhen

movingforward.Also,allowthepedaltomovetothe

NEUTRALpositiontostopthemachine.Donotrestthe

heelofyourfootonreversewhenoperatingforward

(Figure19).

g008430

Figure18

1.Tractionpedal3.Parking-braketab

2.Brakepedal

g005105

Figure19

BrakePedal

Pressthebrakepedal(Figure18)tostopthemachine

byactuatingthefront-wheelbrakes.
