125-6112
1.Exit-sidelockout—resetlight
14.Worklights—Off
2.Exit-sidelockout—drill-enabledlight15.Pressandholdtoincreaseenginespeed.
3.Receiver-battery-statuslight16.Enginespeed
4.Engine—start17.Pressandholdtodecreaseenginespeed.
5.Pressdowntostoptheengine;pulluptostarttheengine.
18.ModeI—lefttriggerreleased,extendspipegrippertoward
drillframe;lefttriggerpressed,openslowerwrench.Mode
II—spindrillspindleclockwise.
6.ResetZap-Alertsystem
19.ModeI—lefttriggerreleased,extendspipegrippertoward
pipeholder;lefttriggerpressed,closeslowerwrench.Mode
II—spindrillspindlecounterclockwise.
7.Zap-Alertsystemtriggered
20.ModeI—lefttriggerreleased,lowerspipeelevator;lefttrigger
pressed,opensupperwrench.ModeII—lefttriggerreleased,
extendspipegrippertowarddrillframe;lefttriggerpressed,
opensupperwrench.
8.Unlockexit-sidelockout
21.ModeI—lefttriggerreleased,raisespipeelevator;lefttrigger
pressed,closesupperwrench.ModeII—lefttriggerreleased,
extendspipegrippertowardpipeholder;lefttriggerpressed,
closesupperwrench.
9.Resetexit-sidelockout
22.Withtriggerreleased,rockforwardtorotatepipeloader
towardpipecam,rockbackwardtorotatepipeloadertoward
drillframe.
10.Engagedrivemovementandsetupfunctions
23.Withtriggerreleased,upperbuttonclosespipegripper,lower
buttonopenspipegripper.
11.Engagedrillcarriagemovementandotherdrillfunctions24.Withtriggerpressed,rockforwardtorotatetheupperwrench
counterclockwisetoloosenajoint;rockrearwardtorotatethe
upperwrenchclockwisetotightenajoint.
12.Worklights—On25.Withtriggerpressed,pressfrontorrearbuttontoresume
thepreviouslysetauto-drillspeed;pressandholdthefront
buttontoincreasetheauto-drillspeed;pressandholdthe
rearbuttontodecreasetheauto-drillspeed.
13.Worklights
17
