DrillFrameandStabilizerControls
g021843
1 2 3
Figure19
1.Drill-frametiltlever
3.Right-stabilizerlever
2.Left-stabilizerlever
StabilizerLevers
Usethestabilizerleverstoraiseandlowerthestabilizers.
Note:TheDRIVE/DRILLswitchontheoperatorpanelmust
beswitchedtotheDRIVEpositionforthisfunctiontowork.
Drill-FrameTiltLever
Usethedrill-frametiltlevertotiltthedrillframetoplace
thestake-downplateonthegroundortoreturntheframe
tothetravelposition.
Note:TheDRIVE/DRILLswitchontheoperatorpanelmust
beswitchedtotheDRIVEpositionforthisfunctiontowork.
DrivePendant
RefertoFigure17forlocation.
g021855
1
2
4
3
5
Figure20
1.Engine-speedswitch4.Drive-speedswitch
2.Drive-directionjoystick
5.Operator-presenceswitch
3.Engine-stopbutton
Engine-StopButton
Pressthisbuttontoimmediatelystoptheengineandall
movement/drillingoperations.Youmustpullthisbuttonout
beforeyoucanstarttheengineagain.
Engine-SpeedSwitch
•Pressandholdthetopofthisswitchtoincreasethe
enginespeed.
•Pressandholdthebottomofthisswitchtodecreasethe
enginespeed.
•Releasetheswitchtomaintainthecurrentenginespeed.
Drive-DirectionJoystick
Usethejoysticktocontrolthedirectionofthemachine.The
machinewilltravelinthedirectionyoumovethejoystick.
28
