2.Pullthehoodlatchout(Figure60).

Figure60

1.Hoodlatch

3.LiftupthehandleasshowninFigure61.

Figure61

1.Hoodhandle

UsingtheCylinderLock

WARNING

Thethrustframemaylowerwhenitisintheraised

position,causingseriousinjuryordeath.

Installthecylinderlockbeforeperforming

maintenancethatrequiresthethrustframetobe

raised.

InstallingtheCylinderLock

1.Starttheengine.

2.Lowerthethrustframetothefully-loweredposition.

3.Stoptheengine.

4.Positionthecylinderlockoverthecylinderrod(Figure

62).

5.Securethecylinderlockwiththecotterpinandclevis

pin(Figure62).

6.TurntheenginetotheONposition,andraisethe

thrustframeuntilitrestsonthecylinderlock.

Figure62

1.Cotterpin4.Clevispin

2.Cylinderlock5.Liftcylinder

3.Liftcylinderrod

RemovingandStoringtheCylinder

Lock

1.Starttheengine.

2.Lowerthethrustframetothefullyloweredposition.

3.Stoptheengine.

4.Removethecotterpinandtheclevispinthatsecurethe

cylinderlock(Figure62).

5.Removethecylinderlock.

6.TurntheenginetotheONposition,andraisethe

thrustframe.
