Exit-Side-LockoutSystem(Standard
Range)
Theexit-side-lockoutsystemprovidestheindividualsworking
aroundthemachinewithameanstodisablethedrillpipe
fromrotatingandthrusting.
Formoreinformationandinstructions,refertotheOperator’s
ManualfortheExit-side-lockoutsystem.
Exit-Side-LockoutSystem(Long
Range)
Theexit-side-lockoutsystemprovidestheindividualsworking
aroundthemachinewithameanstodisablethedrillpipe
fromrotatingandthrusting.
Formoreinformationandinstructions,refertotheOperator’s
ManualfortheExit-side-lockoutsystem.
RearControlPanel
g021837
1
2
3
4
5
Figure17
1.Engine-heatinglight4.Drill-pendantreceptacle
2.Engine,keyswitch5.Drive-pendantreceptacle
3.Fluid-pumpswitch
Engine-HeatingLight
Whentheengineiscold,theheaterwarmstheintakeairto
enableeasierstarting.Thislightilluminateswhiletheheateris
on.Waituntilthislightturnsoffbeforestartingtheengine.
Engine,KeySwitch
Thekeyswitchhas3positionsasfollows(Figure18):
1
2
3
G0221 15
Figure18
1.Engine-offposition
3.Engine-startposition
2.Engine-runposition
•Engine-offposition—turnthekeytothispositionto
stoptheengine.Theenginecannotbestartedfromthe
operatorplatformwhenthekeyisinthisposition.
•Engine-runposition—turnthekeytothispositionafter
startingtheengine.Turningthekeytothisposition
alsoenablestheenginestartbuttonfromtheoperator
platform.
•Engine-startposition—turnthekeytothispositionto
starttheengine.ReleasethekeytotheRUNpositiononce
theenginehasstarted.
Fluid-PumpSwitch
Usethisswitchtoturnontheuidpumptousethespraygun
whencleaningthemachine.
Drill-PendantReceptacle
Plugthedrillpendantintothisreceptacletoattachittothe
machine(Figure17).
Drive-PendantReceptacle
Plugthedrivependantintothisreceptacletoattachittothe
machine(Figure17).
27
