ChargingtheBattery
WARNING
Chargingthebatteryproducesgassesthatcan
explode.
Donotsmokenearthebatteryandkeepsparksand
amesawayfrombattery.
Important:Keepthebatteryfullycharged.Thisis
especiallyimportanttopreventbatterydamagewhen
thetemperatureisbelow32°F(0°C).
1.Parkthemachineonalevelsurface,stoptheengine,
andremovetheignitionkey.
2.Openthefronthood.
3.Cleantheexteriorofthebatterycaseandthebattery
posts.
Note:Connecttheleadsofthebatterychargerto
batterypostsbeforeconnectingthechargertothe
electricalsource.
4.Lookatthebatteryandidentifythepositiveand
negativebatteryposts.
5.Connectthepositiveleadofthebatterychargertothe
positivebatterypost(Figure93).
1
2
3
4
G003792
Figure93
1.Positivebatterypost
3.Red(+)chargerlead
2.Negativebatterypost
4.Black(-)chargerlead
6.Connectthenegativeleadofthebatterychargertothe
negativebatterypost(Figure93).
7.Connectthebatterychargertotheelectricalsource.
Important:Donotoverchargethebattery.
Note:Chargethebatteryashowninbatterycharging
table.
Battery-ChargerTable
ChargersettingChargingtime
4to6amperes30minutes
25to30amperes10to15minutes
8.Whenthebatteryisfullycharged,unplugthecharger
fromtheelectricalsource,thendisconnectthecharger
leadsfromthebatteryposts(Figure93).
Jump-StartingtheMachine
WARNING
Jump-startingthebatterycanproducegassesthat
canexplode.
Donotsmokenearthebatteryandkeepsparksand
amesawayfrombattery.
Note:Thisprocedurerequires2peopletoperform.Ensure
thatthepersonmakingtheconnectionswearstheproperface
protection,protectivegloves,andclothing.
1.Parkthemachineonalevelsurface,stoptheengine,
andremovetheignitionkey.
2.Openthefronthood.
3.EnsurethatallcontrolsareintheNEUTRALposition.
4.Sitintheoperatorseatandhavetheotherpersonmake
theconnections.
Note:Ensurethatthejumperbatteryisa12-volt
battery.
Important:Ifyouareusinganothermachine
forpower,ensurethatthe2machinesarenot
touchingeachother.
5.Preparetostarttheengine;refertoStarting/Stopping
theEngine(page43).
6.Removethecoverfromthejumppost(Figure94).
73
