SPECIFICATIONS
1 - 4 260 Series Tractor Service Manual
Hydrostatic Transaxles
Identification:
Hydro-Gear Model 322-3000 & 330-3000 Transaxle
MVC-082X
General Specifications
F9260-09
General Specifications
Used 2000 to 2002
Lubrication SAE 20W-50 API Classification SH/CD
Oil Capacity 3.8 qt. (3.6liters)
Oil Level The transaxle is a sealed system and does not require periodic checking. If the oil needs to be
checked, IT CAN ONLY BE CHECKED COLD. There is a plug located on the right rear side
of the transaxle. Using a ¼ inch Allen wrench, slowly remove the plug. Oil level should be to
the bottom of the port.
Ground Speed Forward 0 – 6.3 MPH (10.1km/h)
Reverse 0 – 2.3 MPH (3.7km/h)
