260 Series Tractor Service Manual 1 - 1
SPECIFICATIONS
General Specifications
Weight (Net Weight)
Item Specification
Engines All tractors since 1994 were manufactured with Kohler engines ranging from 14
to 20 Horsepower. For more information on servicing the engines, please
contact the Kohler Company.
Domestic Units High RPM Setting (no load) 3250 +/- 100 RPM
International Models High RPM Setting (no load) 2700 +/- 100 RPM
Fuel Capacity 3.9 Gallons (14.7 liter)
Wheel Base 49.5” (125.7cm)
Length 69.0” (175.2cm)
Width 35.5” (90.1cm) without the mower
Steering Sector and Pinion
Turning Radius 16 in. (40.6cm)
Electrical System 15 amp regulated DC alternator
Model Weight
264-6 / 265-6 521 lbs. (236.3kg)
264-H / 265-H (Tuff Torq) 510 lbs. (231.3kg)
267-H / 268-H (Tuff Torq) 540 lbs. (244.9kg)
269-H / 270-H (Tuff Torq) 560 lbs. (254.0kg)
265-H/266-H (Hydro-Gear) 530 lbs. (240.4kg)
268-H (Hydro-Gear) 560 lbs. (254.0kg)
270-H (Hydro-Gear) 580 lbs. (263.0kg)
