Toro Groundsmaster 3310 Series User Manual

1
RemovingtheMachinefrom
theShippingContainer
ModelNo.31902Only
NoPartsRequired
Procedure
1.Removethescrewsthatholddowntherear
wheelhubstothepallet.
2.Cutthecabletiethatholdsthedriveshafttothe
reartires.
3.Removetherearwheelsfromtheshippingskid.
4.Raisetherollbar;refertoRaisingtheRollBar
(page27).
5.Connectahoisttothetop,centerareaoftheroll
barandraisethemachine.
6.Removetheshippingskidfromthebottomarea
ofthemachine.
7.Position2jackstandsundertherearareaof
themachineshowninRaisingtheRearofthe
Machine(page41).
8.Lowerthemachineonthejackstands.
2
InstallingtheRearTires
ModelNo.31902Only
Partsneededforthisprocedure:
2Rearwheel
8Lugnut
Procedure
1.Use4lugnutstosecurethewheeltothewheel
hub(Figure3).
g299549
Figure3
1.Wheelhub3.Lugnut
2.Tire
2.Torquethewheellugnuts;refertoT orquingthe
Wheel-LugNuts(page52).
3
RemovingtheFrontTires
ModelNo.31902Only
NoPartsRequired
Procedure
Note:Youmustperformthisproceduretocorrectly
installtheliftarms.
1.Placejackstandsunderthefrontside-frame
tubestoraisethefrontwheels;refertoRaising
theFrontoftheMachine(page40).
2.Loosenandremovethewheellugnuts(Figure
11).
11
