Toro Groundsmaster 3310 Series User Manual

7
InstallingtheSeat
ModelNo.31902Only
Partsneededforthisprocedure:
1
SeatKit(orderedseparately;refertoyourauthorized
Torodistributor)
Procedure
Installtheseat;refertotheSeatKitInstallation
Instructions.
8
InstallingtheSteering
Wheel
ModelNo.31902Only
Partsneededforthisprocedure:
1
Steeringwheel
1
Cover
Procedure
1.Removethesteeringwheelfromtheshipping
skid(Figure13).
g307379
Figure13
1.Cover4.Steeringwheel
2.Nylocknut
5.Foamcollar
3.Washer
2.Removethenylocknutandwasherfromthe
steeringshaft.
Note:Ensurethatthefoamcollarremainson
thesteeringshaft(Figure13).
3.Slidethesteeringwheelandwasherontothe
steeringshaft(Figure13).
4.Usethenylocknuttosecurethesteeringwheel
totheshaft.Tightenthenylocknutto27to35
N∙m(20to26ft-lb).
5.Mountthecovertothesteeringwheel(Figure
13).
