therecommendedpressuresettingforthe
attachment.
•Rotatetheadjustingscrewclockwiseto
increasethepressure.
•Rotatetheadjustingscrewcounterclockwise
todecreasethepressure.
Attachment
Weight-TransferPressure
Rotarycuttingunit
1,724kPa(250psi)
FlailMower(ModelNo.
02835)
1,379kPa(200psi)
Snowthrower1,724kPa(250psi)
SnowBlade(ModelNo.
23350)
1,379kPa(200psi)
SnowBroom1,724kPa(250psi)
9.Shutofftheengineandremovethekey.
10.Tightenthejamnutattheendofthe
weight-transferspool,andtorquethenutto13
to16N∙m(10to12ft-lb).
11.Installthecaponthetestport.
12.Removethepressuregaugefromthetestport.
ProductOverview
g219621
Figure18
1.Cuttingunit
7.Rollbar
2.Tractionpedal
8.Hood/enginecompartment
3.Hydraulic-uidtank
9.Battery
4.Steeringwheel
10.Fueltank
5.Console
11.Parkingbrake
6.Operator’sseat12.PTOshaft
Controls
TractionPedal
Note:Adjusttheseatpositionbeforeyouoperatethe
machine.RefertotheseatkitInstallationInstructions
forseat-adjustmentinstructions.
Usethetractionpedal(Figure19)tomovethe
machineforwardorrearward.
•Movethemachineforward:Useyourtoesto
pressthetopofthepedal.
•Movethemachinerearward:Useyourtoesto
pressthebottomofthepedal.
Note:Youcanachievesteadyoperationbykeeping
yourheelontheplatformandpressingthepedalwith
yourtoes.
Groundspeedisproportionatetohowfarthepedal
ispressed.Formaximumgroundspeed,youmust
fullypresstractionpedalwhilethrottleisintheFAST
position.Maximumspeedforwardis24km/h(15
mph).
