DisconnectingtheBattery
WARNING
Batteryterminalsormetaltoolscouldshort
againstmetalcomponents,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
machine.
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
1.Removethenegativebatterycablefromthe
batterypost(Figure54).
g289503
Figure54
1.Negativebatterycable2.Positivebatterycable
2.Lifttheinsulatorandremovethepositivebattery
cablefromthebatterypost(Figure54).
ConnectingtheBattery
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative(black)
cable.
1.Connectthepositivecabletothebatteryand
tightenthebattery-clampnut(Figure55).
g289502
Figure55
1.Positivebatterycable2.Negativebatterycable
2.Connectthenegativecabletothebatteryand
tightenthebattery-clampnut(Figure55).
Important:Ensurethatthecable-clamp
fastenersdonotinterferewiththefueltank.
49
