10
Cutting Unit
Type
126 in. (320 cm) width of cut, seven blade, front mounted rotary; 54 in. (137 cm)
width of cut, three blade center section; two 36 in. (91 cm) width of cut wings, 90 in.
(229 cm) width of cut with one wing up; rear discharge with even dispersion over
the entire width of cut
Mowing Rate Mows up to 8 acres/hr (32,375 m
2
) at 6.5 MPH (10.5 km/h)
Trimability Trims on both sides
Height-of-Cut Adjustable from 1 to 5 in. (2.5 to 12.7 cm) in 1/2 in. (1.3 cm) increments
Construction
Housings are 12 gauge high strength steel, 5.5 in. (14 cm) deep, welded
construction and reinforced with 10 gauge channel. Covers are impact resistant,
molded plastic.
Cutter Drive
PTO driven gear box with 1:1 spiral bevel gears. Triple 3V section belt to center
deck spindles, “B” section belt to each wing deck with patented belt routing.
1-1/4 inch diameter, spindle shafts mounted on two greaseable, tapered roller
bearings. A positive splined connection attaches pulleys to spindle shafts for high
torque capacity.
Blades
Seven 19 in. (48 cm) long, 1/4 in. (0.6 cm) thick, and 2-1/2 (6.4 cm) wide, heat
treated steel blades
Belt Idlers Self-tensioning permanently lubricated idlers
Wing Decks
Wings can be hydraulically raised from the operator’s seat for transport or cutting
with either wing and center deck or center deck only. Wings cut from level to 15° up
and down. Further lift disengages the blade and applies a blade brake.
Suspension/Castor
Wheels
Four front and two rear pneumatic castor tires with ball bearings. Center deck tires:
10.25 x 3.25 in. Wing deck tires: 8 x 3.25 in. Anti-scalp cup located on each blade.
Three anti-scalp rollers on center deck. Deck is hydraulically counterbalanced.
Measurements (approx.)
Overall length
(with deck installed)
134 in. (34 m)
Overall width
Transport
Mowing
75 in. (1.9 m)
127 in. (3.23 m)
Height
with ROPS installed
58 in. (1.5 m)
82 in. (2.1 m)
Wheel Tread
Front
Rear
51 in. (130 cm)
41 in. (104 cm)
Wheel base 52 in. (132 cm)
Dry weight
2-wheel drive
4-wheel drive
3800 lb. (1724 kg)
3900 lb. (1769 kg)
Optional Equipment
Broom Kit*
Snowthrower*
Roll Over Protection Kit*
(Standard on Model 30455)
Four Post Canopy Kit*
Spark Arrestor Muffler Part No. 94-5637
Segmented Wheel Kit Part No. 76-1880
Brake Light Kit Part No. 92-7763
Gear Box Pulley
(Tip Speed 14,500)
Part No. 86-3100
Windshield Kit*
Cruise Control Kit Model No. 30485
Road Light Kit Model No. 30471
Mulcher Kit Model NO. 30475
Cab*
Additional Weights*
Low Seat Option*
* Contact your local Toro distributor
Specifications and design subject to change without notice.
