Toro groundsmaster 455-D User Manual

41
Adjusting the Safety Door
On each side of the center deck is a safety door that opens
and closes as the wing decks are lowered and raised
(Fig. 68). The doors open to provide overlap of the cutting
blades when the wing units are down. The doors close to
provide safety and protection when the wing units are
raised. Check to make sure the forward, lower edge of door
(Fig. 68) is even or 1/4 in. (6 mm) higher then lower edge
of door guide when wing decks are in the fully raised,
transport position. If an adjustment to the door is required,
proceed as follows:
1. Loosen jam nuts securing ball joints to threaded rod
(Fig. 68).
1
2
3
Figure 68
1. Safety door
2. Door guide
3. Ball joint
2. Rotate threaded rod to raise or lower edge of door until
is even or 1/4 in. (6 mm) higher then lower edge of door
guide when wing decks are in the fully raised, transport
position.
3. Tighten jams nuts to lock adjustment.
Check for proper operation of the safety
doors each time the deck is cleaned and
repair as needed.
Caution
Adjusting the Blade
To ensure proper operation of the cutting unit, there must
be 0.25 ± 0.12 in. (6 ± 3 mm) clearance between the tips of
the wing and center cutting unit blades (Fig. 69).
1. Raise cutting unit so blades are visible and block center
deck section so it cannot fall accidentally. Wing decks
must be horizontal to center cutting unit.
2. Rotate a center and adjoining wing blade so there blade
tips are aligned. Measure distance between blade tips,
distance should be approximately 0.25 ± 0.12 in.
(6 ± 3 mm) (Fig. 69).
0.25  0.12 in.
(6  3 mm)
Figure 69
3. To adjust distance, locate adjuster bolt on rear outside
corner of center cutting unit (Fig. 70). Loosen jam nut
on adjuster bolt. Loosen or tighten adjuster bolts until
0.25 ± 0.12 in. (6 ± 3 mm) clearance is attained, then
tighten jam nut.
4. Repeat procedure on opposite side of cutting deck.
1
2
Figure 70
1. Adjuster bolt 2. Jam nut
Important Blade plane is adjusted at the factory and
should not need further adjustment.
