Workman MD/MDX Page 6 -- 5 Electrical System
Troubleshooting
CAUTION
Remove all jewelry, especially rings and
watches, before doing any electrical trouble-
shooting or testing. Disconnect the battery
cables unless the test requires battery voltage.
For effective troubleshooting and repairs, you must
have a good understanding of the electrical circuits and
components used on this vehicle (see Wiring Schemat-
ics in Chapter 8 -- Electrical Diagrams).
If the vehicle has any interlock switches by--passed,
they must be reconnected for proper troubleshooting
and safety.
Starting Problems
Problem Possible Causes
Starter solenoid clicks, but starter will not crank. Battery is discharged.
Battery cables are loose or corroded.
Battery ground to frame is loose or corroded.
Wiring at starter is faulty.
Starter solenoid is faulty.
Starter is faulty and causing an incomplete circuit for
the solenoid.
Nothing happens when start attempt is made. Battery is discharged.
Wiring to the start circuit components is loose,
corroded or damaged (see Wiring Schematics in
Chapter 8 -- Electrical Diagrams).
Battery cables are loose or corroded.
Battery ground to frame is loose or corroded.
Fuse block is faulty.
10 ampere fuse to the ignition switch is loose or blown.
The ignition switch is faulty.
Switch at accelerator pedal is faulty or needs
adjustment.
Starter solenoid is faulty.
Shutdown module is faulty (Workman MDX).
Engine cranks, but does not start. Wiring to start circuits is loose, corroded or damaged
(see Wiring Schematics in Chapter 8 -- Electrical
Diagrams).
Shutdown module is faulty (Workman MDX).
Engine or fuel system is malfunctioning (see Engine
Chapter).
Engine and fuel may be too cold.
Electrical
System
