Workman MD/MDX Page 7 -- 1 Chassis
Chapter 7
Chassis
Table of Contents
GENERAL INFORMATION 1.....................
Operator ’s Manual 1..........................
SPECIFICATIONS 2............................
SPECIAL TOOLS 2.............................
TROUBLESHOOTING 3.........................
Suspension and Steering 3....................
Brakes 4.....................................
ADJUSTMENTS 6..............................
Adjust Parking Brake 6........................
Adjust Front Wheel Camber 7..................
Adjust Front Wheel Toe--in 8...................
SERVICE AND REPAIRS 9......................
Check Tire Pressure 9.........................
Inspect Tires and Wheels 9....................
Upper Steering 10............................
Steering Gearbox 12..........................
Lower Steering and Front Wheels 14............
Front Shock Absorbers 17.....................
A-- arms and Front Suspension 18...............
Frame Pivot Yoke 20..........................
Swing Arm 22................................
Parking Brake 26.............................
Rear Wheels and Brakes 28....................
Rear Brake Service 30........................
Front Brake Calipers 32.......................
Front Brake Caliper Service 34.................
Brake Master Cylinder 36......................
Brake Master Cylinder Service 38...............
Bleed Brake System 39........................
Seat Base 40.................................
Front Hood 42................................
Cargo Box (Serial Numbers Below 311000000) 44
Cargo Box (Serial Numbers Above 311000000) 46
General Information
Operator’s Manual
The Operator ’s Manual provides information regarding
the operation, general maintenance and maintenance
intervals for your Workman vehicle. Refer to the Opera-
tor’s Manual for additional information when servicing
the machine.
Chassis
Rev. A
