Workman MD/MDX Page 1 -- 5 Safety
Transaxle Neutral Position
When performing routine maintenance and/or engine
testing, the transaxle must be shifted into the neutral
position.
1. Park machine on a level surface, stop engine, set
parking brake and remove key from the ignition switch.
2. Move shift lever to the neutral position (Fig. 3).
3. Make sure transaxle is in the neutral position by ro-
tating the driven clutch. The tires should not rotate. If tire
rotation does occur, see Adjust Shift Cables in the Ad-
justment section of Chapter 5 -- Drive Train.
1. Shift lever (in neutral)
2. Forward position
3. Reverse position
Figure 3
1
3
2
Safety
