11.5 Temperature/Humidity Sensor
11.5.1 General description
This sensor measures the temperature and humidity inside the equipment.
11.5.2 Construction
Temperature/humiditycontrolcircuitisconguredasfollows:
Fig. 11-501
R TH
+
-
CPU
PC7/AN7
PC3/AN3
HMS-1A
TEMP-1A
LGC board HUMI-THS
