E6582051
- 14 -
3. Parameters
3.1.
Communication parameters
This option doesn't operate if these parameters are not correctly set.
Title
Communi
cation No.
Function Description
Default
setting
cmod
0003 Command mode selection
0: Terminal board
1: Panel keypad (including remote keypad)
2: RS485 communication
3: CANopen communication
4: Communcation option
1
fmod
0004
Frequency setting mode
selection 1
0: Setting dial 1 (save even if power is off)
1: Terminal board VIA
2: Terminal board VIB
3: Setting dial 2 (press in center to save)
4: RS485 communication
5: UP/DOWN from external logic input
6: CANopen communication
7: Communication option
8: Terminal board VIC
9, 10: -
11: Pulse train input
12, 13: -
14:
sr0
0
f519
0519
Setting of acceleration /
deceleration time unit
0: -
1: 0.01s unit (after execution: 0)
2: 0.1s unit (after execution: 0)
0 (*3)
f749
0749
Integrating wattmeter display
unit selection
0:1=1kWh
1:1=10kWh
2:1=100kWh
3:1=1000kWh
4:1=10000kWh
(*1)
f856
0856
Number of motor pole pair for
communication
1: 2 poles
2: 4 poles
3: 6 poles
4: 8 poles
5: 10 poles
6: 12 poles
7: 14 poles
8: 16 poles
2
f899
0899 Communication function reset
0: -
1: Reset (after execution: 0)
-
c081-
c096
C081-
C096
Device Name 1-16 (*2)
16 characters
The device name is required if the card uses DHCP
to obtain its IP Address.
0
(*1): Default setting values vary depending on the capacity.
(*2): (
typ
) does not work for this parameter.
(*3): 0.1s unit is selected as default setting.
