Toshiba PNE001Z User Manual

E6582051
- 26 -
5. Vendor Specification Profile
Cyclic command transmission is possible for PNE001Z by the original profile
Select the ”Telegram 100”, ”Telegram 101” or ”Telegram 102” as the profile on the configuration. Refer
to the PLC configuration tool documents.
You will be able to select the command and monitor items from the following table.
Please execute these settings by the configuration tool of controller.
Scanner input
c001
-
c006
Scanner output
c021
-
c026
0: No action
1:
fa06
(Communication command 1)
2:
fa23
(Communication command 2)
3:
fa07
(Frequency command, 0.01Hz)
5:
fa50
(Terminal output data)
6:
fa51
(FM analog output)
8:
f601
(Stall prevention level, %)
13:
acc
(Acceleration time 1, 0.1s)*
14:
dec
(Deceleration time 1, 0.1s) *
15:
ul
(Upper limit,0.01Hz)
16:
vb
(Torque boost value 1,0.1%)
17:
vlv
(Base frequency voltage 1, 0.1V)
0: No action
1:
fd01
(Status information 1)
2:
fd00
(Output frequency, 0.01Hz)
3:
fd03
(Output current, 0.01%)
4:
fd05
(Output voltage, 0.01%)
5:
fc91
(Alarm information)
6:
fd22
(PID feedback value, 0.01Hz)
7:
fd06
(Input terminal board status)
8:
fd07
(Output terminal status)
9:
fe36
(VIB input, 0.01%)
10:
fe35
(VIA input, 0.01%)
11:
fe37
(VIC input, 0.01%)
12:
fd04
(Input voltage (DC detection), 0.01%)
13:
fd16
(Estimated speed (real-time value), 0.01Hz)
14:
fd18
(Torque, 0.01%)
19:
f880
(Free notes)
20:
fd29
(Input power, 0.01kW)
21:
fd30
(Output power, 0.01kW)
22:
fe14
(Cumulative operation time, hour)
23:
fe40
(FM terminal output monitor, 0.01%)
25:
fd20
(Torque current, 0.01%)
26:
fd23
(Motor overload factor, 0.01%)
27:
fd24
(Drive overload factor, 0.01%)
28:
fd25
(PBR overload factor, %)
29:
fd26
(Motor load factor, %)
30:
fd27
(Drive load factor, %)
31:
fe56
(Pulse train input, pps)
32:
fe70
(Drive rated current, 0.1A)
33:
fe76
(Input Watt-hour, 0.1kWh

10
f749
) **
34:
fe77
(Output Watt-hour, 0.1kWh

10
f749
) **
35:
fd83
(IGBT temperature, degree C)
* The unit of
acc
,
dec
is according to the parameter
f519
.
** The unit of
fe76
,
fe77
is according to the parameter
f749
.
