Toshiba PNE001Z User Manual

E6582051
- 60 -
9. Specifications
Module specifications
Item Specification
Type-form PNE001Z
Applicable inverter VF-S15 CPU1 Ver.112 or later (With SBP009Z)
Connector Dual RJ45 shielded connector
Supported network PROFINET, Modbus TCP
Indicator
4 LEDs indicating the communication status and error
status.
Protection degree IP20
Environments Correspond to inverter.
Network specifications
Item Specification
PROFINET
Baud rate 100Mbps (Full duplex)
Cyclic communication
PROFIdrive V.4.1 (Telegram1)
4PKW and 2 PZD vendor format (Telegram100)
4PKW and 6 PZD vendor format (Telegram101)
6 PZD vendor format (Telegram102)
Acyclic communication
Reading the PROFIdrive parameter
Reading/writing the inverter parameters
Configuration Configure by PROFINET master
IP configuration mode Manual setup, DCP, DHCP, Embedded Web server
PROFINET IO classes Conformance Class-B
I&M I&M function 0
Modbus TCP
Baud rate 10/100Mbps (Full/Half duplex)
Supported function
Read Holding Registers (03H)
Write Single Register (06H)
Write Multiple Registers (10H)
Read Device Identification (2BH)
IP configuration mode Manual setup, DHCP, Embedded Web server
Ethernet
MRP Supported
LLDP Supported
Web server
Inverter status monitor, inverter parameter
monitor/configuration, Network status monitor,
password lock
