E6582051
- 35 -
5.7.
PROFIdrive parameter (PNU)
PNU R/W data type Note
915 R Array [6]
Unsigned16
PNU 915, IND 0 = the drive parameter c001
PNU 915, IND 1 = the drive parameter c002
PNU 915, IND 2 = the drive parameter c003
PNU 915, IND 3 = the drive parameter c004
PNU 915, IND 4 = the drive parameter c005
PNU 915, IND 5 = the drive parameter c006
916 R Array [6]
Unsigned16
PNU 916, IND 0 = the drive parameter c021
PNU 916, IND 1 = the drive parameter c022
PNU 916, IND 2 = the drive parameter c023
PNU 916, IND 3 = the drive parameter c024
PNU 916, IND 4 = the drive parameter c025
PNU 916, IND 5 = the drive parameter c026
922 R Unsigned16 Telegram selection ( same as the drive parameter c152)
1, 100, 101, 102
923 R Unsigned16 List of all the parameters for signals
930 R Unsigned16 Operating mode
1: supports the speed control mode and the speed setpoint
channel comprises RFG functionality.
944 R Unsigned16 Fault message counter
947 R Array [1]
Unsigned16
Fault number
964 R
Array [5]
Unsigned16
Drive Unit identification
IND 0 = Manufacturer-ID (0x0190)
IND 1 = Model number
IND 2 = VF-S15 CPU1 version
IND 3 = VF-S15 firmware release year (yyyy)
IND 4 = VF-S15 firmware release date (ddmm)
965 R Octet String2 Profile number (PROFIdrive, V4.1)
