3.29 LAN/Modem/Bluetooth/IEEE1394 Test Program 3 Tests and Diagnostics
QOSMIO F20 Maintenance Manual (960-526) [CONFIDENTIAL] 3-75
3.29.2 Modem test
For this subtest, connect the modem PCB and RJ11 connector with a harness. Use the dedicated
“FAT-MODE inspection device (product code: QE2000P01 made by Nitto Electric Manufacture
Co.,Ltd)” for the tests.
To execute Modem test, press 2 and Enter. Following message will appear:
[Modem loopback test !]
ICHx MDC Test Program with Modem Sound (Line Test)
Version X.X
* Scorpio Modem Initialize :OK
* Digital Loopback Test :OK
* RJ11 Connector Check (LED) :(Operator’s Check!!)
NOTE: The menu displayed on your computer may be slightly different from the one
shown above.
RJ11 Connection Check (LED) (Operator’s Check LED) test will be executed, and the following
message will appear:
...Press Key (Y = OK , N =NG)
If the color of the LED of the connection checker is orange, press Y. Otherwise, press N.
