-7-
z
LEDs
LED Status Indication
On The Router is powered on
PWR
Off The Router is powered off or power supply is abnormal
Flashing The Router works properly
SYS
On/Off The Router works improperly
On There is a device linked to the corresponding port
Off There is no device linked to the corresponding port
Link/Act
Flashing The corresponding port is transmitting or receiving data
On (Green) The linked device is running at 1000Mbps
On (Yellow) The linked device is running at 100Mbps
Speed
Off
There is no device linked to the corresponding port or the
linked device is running at 10Mbps
On The port is working in WAN mode
WAN
Off The port is working in LAN mode
On The port is working in DMZ mode
DMZ
Off The port is working in LAN mode
z
Interface Description
Interface Port Description
WAN 1~4
The WAN port is for connecting the Router to a DSL/Cable
modem or Ethernet by the RJ45 cable
LAN 2~5
The LAN port is for connecting the Router to the local PCs or
switches by the RJ45 cable
DMZ 5 The DMZ port is for connecting the Router to the servers
Console /
The Console port is for connecting with the serial port of a
computer or terminal to monitor and configure the Router
z
Reset button
Use the button to restore the Router to the factory defaults. With the Router powered on, use a pin to
