Appendix A Hardware Specifications
Standards
IEEE 802.3、IEEE 802.3u、IEEE 802.3x、TCP/ IP、DHCP、ICMP、NAT、
PPPoE、SNTP、HTTP、DNS、L2TP、PPTP、IPsec
One 10/100/1000M Auto-Negotiation WAN RJ45 port (Auto MDI/MDIX)
Three adjustable 10/100/1000M Auto-Negotiation WAN/LAN RJ45 ports
(Auto MDI/MDIX)
One 10/100/1000M Auto-Negotiation LAN RJ45 port (Auto MDI/MDIX)
Ports
One Console Port
10Base-T: UTP/STP of Cat. 3 or above
100Base-TX: UTP/STP of Cat. 5 or above
Transmission Medium
1000Base-T: UTP/STP of Cat.5e, Cat.6
LEDs
PWR, SYS, Link/Act, Speed, WAN, DMZ
Power
100-240V~ 50/60Hz 0.6A
Operating Temperature: 0ºC ~ 40ºC
Storage Temperature: -40ºC ~ 70ºC
Operating Humidity: 10% ~ 90%RH Non-condensing
Operating Environment
Storage Humidity: 5% ~ 90%RH Non-condensing
