Trane Airfinity XL IH190 User Manual

RT-SVX060D-GB
10
4 UNT-PRC002-GB
Technical Data
FWD 08 12 20 30 45
Power supply (V/Ph/Hz) 230/1/50
Capacities
Cooling capacity on water (1) (kW) 5,2 8,3 15 18,8 30,1
Heating capacity on water (2) (kW) 6,3 11,9 18,9 20,9 38,2
Fan motor (type) 2 x direct drive centrifugal
Fan power input (3) (kW) 0,23 0,46 0,65 1,04 1,51
Current amps (3) (A) 1,1 2,2 3,1 4,7 5,5
Start-up amps (A) 3,2 5,5 9,3 14,1 16,5
Air flow
minimum (m
3
/h) 490 980 1400 1800 2700
nominal (m
3
/h) 820 1650 2300 3000 4500
maximum (m
3
/h) 980 1970 2600 3600 5400
Main coil
Water entering/leaving connections (type) ISO R7 rotating female
(Dia) 3/4" 3/4" 1 1/2" 1 1/2" 1 1/2"
Electric heater (accessory for blower only)
Electric power supply (V/Ph/Hz) 230/1/50 230/1/50 or 400/3/50 400/3/50 400/3/50 400/3/50
Heating capacity (kW) 2/4 8 10 12 12
Hot water coil (accessory for blower only)
Heating capacity (4) (kW) 6,3 12 17,4 22,4 34,5
G2 filter (filter box accessory)
Quantity 2 2 2 2 2
Dimensions ( LxWxth) (mm) 386x221x8 486x271x8 586x321x8 586*421*8 586*621*8
G4 filter (filter box accessory)
Quantity - 2 2 2 2
Dimensions ( LxWxth) (mm) - 486x264x48 586x314x48 586*414*48 586*614*48
Condensate pump (accessory) (type) Centrifugal
Water flow - lift height (l/h - mm) 24 - 500
Not available for FWD30 and FWD45
Sound level (L/M/H speed)
Sound pressure level (5) (dB(A)) 36/40/43 38/41/44 46/50/53 47/52/57 47/52/58
Sound power level (5) (dB(A)) 46/50/53 48/51/54 56/60/63 57/62/67 57/62/68
Unit dimensions
Width x Depth (mm) 890 x 600 1090 x 710 1290 x 820 1290 x 970 1290 x 1090
Height (mm) 250 300 350 450 650
Shipped unit dimensions
Width x Depth (mm) 933 x 644 1133 x 754 1333 x 864 1333 x 1008 1333*1133
Height (mm) 260 310 360 460 660
Weight (kg) 32 46 61 76 118
Colour galvanised steel
Recommended fuse size
Unit alone (aM/gI) (A) 8/16 8/16 8/16 8/25 8/25
Unit with electric heater (gI) (A) 16 (2kW),25 (4kW) 40 (230V),3*16 (400V) 3*20 3*25 3*25
(1) Conditions: Water entering/leaving temperature: 7/12 °C, Air inlet temperature 27/19°C DB/WB - Nominal air flow
(2) Conditions: Water entering/leaving temperature: 50/45 °C, Air inlet temperature 20°C DB - Nominal air flow
(3) At high speed with nominal air flow.
(4) Water entering/leaving temperature 90/70 °C, air inlet temperature 20 °C DB, Nominal air flow.
(5) A rectangular glass wool duct 1m50 long is placed on the blower.The measurement is taken in the room containing the blower unit.
Heat exchanger operating limits:
FWD:
*water temperature: max 100° C
*absolute service pressure: min 1 bar/max 11 bars
Accessories - Hot water coil:
*water temperature: min. +2° C/max. 100° C
*absolute service pressure: min 1 bar/max 11 bars
IC140 IC150 IC170 IC190 IC220 IC250 IC270
Indoor Coil
Type Fins & Tubes
Tube Size Inches 3/8” 3/8” 3/8”
3/8” 3/8” 3/8” 3/8”
Face Area m
2
3.65 3.65 3.65
3.65 3.65 3.65 3.65
Rows/Fin Series #/FPF 3 / 168 3 / 168 4 / 168
4 / 168 4 / 168 4 / 168 4 / 168
Drain Connection outside diameter mm 34 34 34
34 34 34 34
Indoor Fan
Standard
Type Plug Fans Plug Fans Plug Fans
Plug Fans Plug Fans Plug Fans Plug Fans
Model
K3G500PA
2377
K3G500PA
2377
K3G500PB
3377
K3G500PA
2377
K3G500PB
3377
K3G500PB
3377
K3G500PB
3377
Minimum Airow m
3
/h 19200 20800 22400
26400 28800 33600 36800
Nominal Airow m
3
/h 24000 26000 28000
33000 36000 42000 44000
Maximal Airow m
3
/h 28800 31200 33600
39600 40000 44000 44000
Number # 3 3 3
4 4 4 4
Diameter mm 500 500 500
500 500 500 500
Drive Type EC Motors EC Motors EC Motors
EC Motors EC Motors EC Motors EC Motors
Max Motor Power per fan kW 3.5 3.5 5.7
3.5 5.7 5.7 5.7
Motor Max Amps per fan A 5.3 5.3 9
5.3 9 9 9
Max motor RPM RPM 1900 1900 2250
1900 2250 2250 2250
Available Static Pressure Pa 400 400 400
400 400 400 400
Oversized
Type Plug Fans Plug Fans Plug Fans
Plug Fans Plug Fans Plug Fans Plug Fans
Model K3G500PB3377
Minimum Airow m
3
/h 19200 20800 22400
26400 28800 33600 36800
Nominal Airow m
3
/h 24000 26000 28000
33000 36000 42000 44000
Maximal Airow m
3
/h 28800 31200 33600
39600 40000 44000 44000
Number # 3 3 4
4 4 4 4
Diameter mm 500 500 500
500 500 500 500
Drive Type EC Motors EC Motors EC Motors
EC Motors EC Motors EC Motors EC Motors
Max Motor Power per fan kW 5.7 5.7 5.7
5.7 5.7 5.7 5.7
Motor Max Amps per fan A 9 9 9
9 9 9 9
Max motor RPM RPM 2250 2250 2250
2250 2250 2250 2250
Available Static Pressure Pa 800 800 800
800 800 800 800
Outdoor Fan
Standard Ambient Fan
Type Axial / Above / AC motor
Model AC motor GPF3B3PM132SS8 GPF3B3PM132SS6
Nominal Airow / ckt m
3
/h 26780 26780 26780
33408 33408 47742 47742
Number of fan / ckt # 2 2 2
2 2 3 3
Diameter mm 800 800 800
800 800 800 800
Motor Power per fan kW 0.75 0.75 0.75
1.57 1.57 1.57 1.57
Motor Max Amps per fan A 1.81 1.81 1.81
3.26 3.26 3.26 3.26
Motor RPM rpm 705 705 705
930 930 930 930
Filter
Filter type preltration layer 50mm G4 or M5
Filtration type layer 100mm F7 or F9 F7 or F9 F7 or F9
F7 or F9 F7 or F9 F7 or F9 F7 or F9
Number of Filters / layer 12 12 12
12 12 12 12
Filter Size mm 500x625 500x625 500x625
500x625 500x625 500x625 500x625
Physical Data for Standard Unit (4)
Length (include fresh air hood) mm 6224 6224 6224
6224 6224 7118 7118
Gas unit extra lenght mm 1357 1357 1357
1357 1357 1357 1357
Width mm 2350 2350 2350
2350 2350 2350 2350
Height mm 2274 2274 2274
2274 2274 2274 2274
Operating Weight (Downow
Without Auxiliary Heat)
kg 2237 2245 2313 2438 2517 2762 2767
