Technical Data
FWD 08 12 20 30 45
Power supply (V/Ph/Hz) 230/1/50
Capacities
Cooling capacity on water (1) (kW) 5,2 8,3 15 18,8 30,1
Heating capacity on water (2) (kW) 6,3 11,9 18,9 20,9 38,2
Fan motor (type) 2 x direct drive centrifugal
Fan power input (3) (kW) 0,23 0,46 0,65 1,04 1,51
Current amps (3) (A) 1,1 2,2 3,1 4,7 5,5
Start-up amps (A) 3,2 5,5 9,3 14,1 16,5
Air flow
minimum (m
3
/h) 490 980 1400 1800 2700
nominal (m
3
/h) 820 1650 2300 3000 4500
maximum (m
3
/h) 980 1970 2600 3600 5400
Main coil
Water entering/leaving connections (type) ISO R7 rotating female
(Dia) 3/4" 3/4" 1 1/2" 1 1/2" 1 1/2"
Electric heater (accessory for blower only)
Electric power supply (V/Ph/Hz) 230/1/50 230/1/50 or 400/3/50 400/3/50 400/3/50 400/3/50
Heating capacity (kW) 2/4 8 10 12 12
Hot water coil (accessory for blower only)
Heating capacity (4) (kW) 6,3 12 17,4 22,4 34,5
G2 filter (filter box accessory)
Quantity 2 2 2 2 2
Dimensions ( LxWxth) (mm) 386x221x8 486x271x8 586x321x8 586*421*8 586*621*8
G4 filter (filter box accessory)
Quantity - 2 2 2 2
Dimensions ( LxWxth) (mm) - 486x264x48 586x314x48 586*414*48 586*614*48
Condensate pump (accessory) (type) Centrifugal
Water flow - lift height (l/h - mm) 24 - 500
Not available for FWD30 and FWD45
Sound level (L/M/H speed)
Sound pressure level (5) (dB(A)) 36/40/43 38/41/44 46/50/53 47/52/57 47/52/58
Sound power level (5) (dB(A)) 46/50/53 48/51/54 56/60/63 57/62/67 57/62/68
Unit dimensions
Width x Depth (mm) 890 x 600 1090 x 710 1290 x 820 1290 x 970 1290 x 1090
Height (mm) 250 300 350 450 650
Shipped unit dimensions
Width x Depth (mm) 933 x 644 1133 x 754 1333 x 864 1333 x 1008 1333*1133
Height (mm) 260 310 360 460 660
Weight (kg) 32 46 61 76 118
Colour galvanised steel
Recommended fuse size
Unit alone (aM/gI) (A) 8/16 8/16 8/16 8/25 8/25
Unit with electric heater (gI) (A) 16 (2kW),25 (4kW) 40 (230V),3*16 (400V) 3*20 3*25 3*25
(1) Conditions: Water entering/leaving temperature: 7/12 °C, Air inlet temperature 27/19°C DB/WB - Nominal air flow
(2) Conditions: Water entering/leaving temperature: 50/45 °C, Air inlet temperature 20°C DB - Nominal air flow
(3) At high speed with nominal air flow.
(4) Water entering/leaving temperature 90/70 °C, air inlet temperature 20 °C DB, Nominal air flow.
(5) A rectangular glass wool duct 1m50 long is placed on the blower.The measurement is taken in the room containing the blower unit.
Heat exchanger operating limits:
FWD:
*water temperature: max 100° C
*absolute service pressure: min 1 bar/max 11 bars
Accessories - Hot water coil:
*water temperature: min. +2° C/max. 100° C
*absolute service pressure: min 1 bar/max 11 bars
IC140 IC150 IC170 IC190 IC220 IC250 IC270
Cooling Mode
Net Cooling Capacity R410A (1) kW 141.1 154.9 171.9 197.0 213.6 234.1 247.4
Total Power Input R410A (1) kW 42.8 50.2 57.9 68.9 80.5 87.2 93.8
Net Cooling Capacity R454B (1) kW 139.7 153.4 169.9 194.6 212.3 233.7 247.7
Total Power Input R454B (1) kW 41.2 47.6 54.6 64.7 75.3 82.2 88.9
Electric Heater
Number of capacity step Nb 2 2 2 2 2 2 2
Capacity Steps (1) kW 37,5/37,5 37,5/37,5 62,5/37,5 62,5/37,5 75/37,5 75/37,5 75/37,5
Gas burner: Low Heat
Gas burner type PCH132 PCH132 PCH132 PCH132 PCH132 PCH132 PCH132
Max. burner heat output G20 (Hi) kW 130 130 130 130 130 130 130
Max. useful heat output G20 kW 126 126 126 126 126 126 126
Max. efciency G20 (Hi) % 96.8 96.8 96.8 96.8 96.8 96.8 96.8
Min. burner heat output G20 (Hi) kW 12.4 12.4 12.4 12.4 12.4 12.4 12.4
Min. useful heat output G20 kW 13.4 13.4 13.4 13.4 13.4 13.4 13.4
Min. efciency G20 (Hi) % 108.1 108.1 108.1 108.1 108.1 108.1 108.1
Modulation % 11% to 100%
Max. condensation (30%Qn) l/h 4.2 4.2 4.2 4.2 4.2 4.2 4.2
Gas connection
ø UNI/ISO 228/1-G 1½”
Gas burner: Standard Heat
Gas burner type PCH162 PCH162 PCH162 PCH162 PCH162 PCH162 PCH162
Max. burner heat output G20 (Hi) kW 164 164 164 164 164 164 164
Max. useful heat output G20 kW 160 160 160 160 160 160 160
Max. efciency G20 (Hi) % 97.6 97.6 97.6 97.6 97.6 97.6 97.6
Min. burner heat output G20 (Hi) kW 16.4 16.4 16.4 16.4 16.4 16.4 16.4
Min. useful heat output G20 kW 17.8 17.8 17.8 17.8 17.8 17.8 17.8
Min. efciency G20 (Hi) % 108.4 108.4 108.4 108.4 108.4 108.4 108.4
Modulation % 11% to 100%
Max. condensation (30%Qn) l/h 6.6 6.6 6.6 6.6 6.6 6.6 6.6
Gas connection
ø UNI/ISO 228/1-G 1½”
Gas burner: High Heat
Gas burner type PCH212 PCH212 PCH212 PCH212 PCH212 PCH212 PCH212
Max. burner heat output G20 (Hi) kW 200.0 200.0 200.0 200.0 200.0 200.0 200.0
Max. useful heat output G20 kW 194.3 194.3 194.3 194.3 194.3 194.3 194.3
Efciency G20 (Hi) % 97.2 97.2 97.2 97.2 97.2 97.2 97.2
Min. burner heat output G20 (Hi) kW 21 21 21 21 21 21 21
Min. useful heat output G20 kW 22.8 22.8 22.8 22.8 22.8 22.8 22.8
Min. efciency G20 (Hi) % 108.4 108.4 108.4 108.4 108.4 108.4 108.4
Modulation % 11% to 100%
Max. condensation (30%Qn) l/h 5.4 5.4 5.4 5.4 5.4 5.4 5.4
Gas connection
ø UNI/ISO 228/1-G 1½”
Hot Water Coil
Type Fins & Tubes
Net Heating Capacity kW 154.80 162.48 169.06 184.80 194 194 194
Tube Size Inches 3/8” 3/8” 3/8” 3/8” 3/8” 3/8” 3/8”
Face Area m
2
1.39 1.39 1.39 1.39 1.39 1.39 1.39
Rows/Fin Series #/FPF 2 / 144 2 / 144 2 / 144 2 / 144 2 / 144 2 / 144 2 / 144
Number of Tubes in the height 32 32 32 32 32 32 32
Drain Connection outside diameter mm DN34 DN34 DN34 DN34 DN34 DN34 DN34
IC General Data
