CVHE-SVX02M-EN
Installation: Controls
This section covers information pertaining to the
UC800 controller hardware. For information about the
Tracer® AdaptiView™ display, which is used to
interface with the internal chiller data and functions
provided by the UC800, refer to Tracer AdaptiView
Display for Water-Cooled CenTraVac Chillers
Operations Guide (CTV-SVU01*-EN).
UC800 Specifications
Power Supply
NNOOTTIICCEE
CCuussttoommeerr WWiirriinngg!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss bbeellooww ccoouulldd rreessuulltt iinn
eeqquuiippmmeenntt oorr pprrooppeerrttyy--oonnllyy ddaammaaggee..
OOnnllyy uussee fflleexxiibbllee ccoonndduuiitt oorr mmeettaall--ccllaadd ccaabbllee wwhheenn
wwiirriinngg tthhee ccoonnttrrooll ppaanneell aanndd mmoottoorr tteerrmmiinnaall bbooxx ttoo
eennssuurree aa vviibbrraattiioonn--ffrreeee iinnssttaallllaattiioonn..
The UC800 (1A22) receives 24 Vac (210 mA) power
from the 1A2 power supply located in the chiller control
panel.
Wiring and Port Descriptions
The following figure illustrates the UC800 controller
ports, LEDs, rotary switches, and wiring terminals. The
numbered list following the figure corresponds to the
numbered callouts in the illustration.
