Triumph Sprint GT 1050 User Manual

92
Maintenance and Adjustment
Suspension Setting Chart
Note:
• These charts are only a guide.
Setting requirements may vary for
rider weight and personal
preferences. See the following
pages for instructions on how to
adjust your suspension.
Sprint ST
Sprint GT
Front Suspension Settings
The standard suspension settings provide a
comfortable ride and good handling
characteristics for general, solo riding. The
chart shows suggested settings for the front
and rear suspension.
The front suspension is adjustable for
pre-load only. The spring pre-load adjusters
are located at the top of each fork.
Note:
• The setting figures for the front
suspension are measured as the
number of adjuster rings visible
above the fork top cap.
LOADING FRONT REAR
Spring
Pre-Load †
Rebound
Damping*
Spring
Pre-Load ‡
Solo Riding 3 1.5 20
Rider and
Passenger or Rider
and Luggage
31.010
Rider, Passenger
and Luggage
30.5 0
† Adjuster rings visible above fork cap.
* Number of adjuster turns in from the fully screwed out (hard)
position.
‡ Number of clicks out from the fully screwed in position.
LOADING FRONT REAR
Spring
Pre-Load †
Rebound
Damping*
Spring
Pre-Load ‡
Solo Riding 3 1.0 30
Rider and
Passenger or Rider
and Luggage
30.2520
Rider, Passenger
and Luggage
30.25 0
† Adjuster rings visible above fork cap.
* Number of adjuster turns in from the fully screwed out (hard)
position.
‡ Number of clicks out from the fully screwed in position.
Warning
Ensure that the correct balance between
front and rear suspension is maintained.
Suspension imbalance could significantly
change handling characteristics leading to
loss of control and an accident. Refer to the
chart on the previous page for further
information or consult your dealer.
Warning
Ensure that the adjusters are set to the
same setting on both forks. Settings which
vary from left to right could significantly
change handling characteristics leading to
loss of control and an accident.

Triumph Sprint GT 1050 Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Engine Capacity	1050 cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Max Torque	108 Nm @ 6, 300 rpm
Exhaust	Stainless steel 3 into 1 exhaust system
Frame	Aluminium beam perimeter
Front Suspension	43 mm upside down forks with adjustable preload
Rear Suspension	Monoshock with adjustable preload and rebound damping
Front Brakes	Twin 320mm floating discs, Nissin 4-piston calipers
Rear Brakes	Single 255mm disc, Nissin 2-piston caliper
Seat Height	815 mm
Fuel Tank Capacity	20 litres
Max Power	130 PS / 128 bhp (96 kW) @ 9200 rpm
