36
Technical data
Batteries
Handset operating times/charging times
The operating time of your handset depends on the capacity and age of the battery and the way it is used.
(All times are maximum possible times).
Power consumption of base station
General specifications
Bluetooth
Technology: 2 x AAA NiMH
Voltage: 1.2 V
Capacity: 750 mAh
Standby time (hours) * 165
Talktime (hours) 12
Operating time with 1.5 hrs of calls per day (hours) * 95
Charging time in base station (hours) 5
Charging time in charging cradle (hours) 7
* without display backlight (Setting the display backlight
p. 29)
The operating times of the phone can be extended by using a more powerful battery.
In standby mode: Handset in charging cradle
Handset not in charging cradle
approx. 1.2 W
approx. 0.55 W
During a call: approx. 0.65 W
DECT standard Supported
GAP standard Supported
No. of channels 60 duplex channels
Radio frequency range 1880-1,900 MHz
Duplex mode Time division multiplexing, 10 ms frame length
Pulse repetition rate 100 Hz
Pulse transmission length 370 µs
Channel grid 1728 kHz
Bit rate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission power 10 mW, average power per channel, 250 mW pulse power
Range Up to 50 m indoors, up to 300 m outdoors
Base station power supply 230 V ~/50 Hz
Environmental conditions for operation +5 °C to +45 °C; 20 % to 75 % relative humidity
Dialing mode DTMF (tone dialing)/ PD (pulse dialing)
Radio frequency range 2402-2480 MHz
Transmission power 4 mW pulse power
