Upright MX Series User Manual

48 “Translation of the original instruction”
Warning
C
5.2 Platform Components
2-1
5.2.1 Method to Remove the Platform
Warning! The risk of physical injury. The
completion of this procedure requires special repair
skills, lifting equipment and suitable workshops.
Without these skills and tools, the execution of this
procedure may result in death or serious injury and
damage to important parts. Ask seller to repair.
Note: This procedure requires the use of the
corresponding load-bearing lifting equipment.
1. Unlock the strap that secures the platform
power supply to the bottom of the platform.
Caution! Risk of damage to parts. Make sure that
the platform power supply wiring is not cut off.
2.Remove the clip that secures the platform controller
cable to the platform.
3.Disconnect the platform controller cable from the
platform controller.
4.Remove the platform control box from the platform
and set it aside.
Caution! Risk of damage to parts. The platform
controller wiring may be damaged when it is distorted
or squeezed.
5.Remove the platform AC power socket cover. Mark
and disconnect the wiring on the socket.
Warning! Risk of electric shock / burn. Exposure to
live circuits can result in death or serious injury.
Remove all rings, watches and other accessories.
Note: If your machine has an air tube option to the
platform, you must disconnect the air tube from the
platform before removing the air tube.
6.Connect the chain from the lifting device to the four
lifting points on the platform.
Warning! The risk of crushing. If the support is not
correct, the platform will fall.
7.Remove the positioning fasteners of the platform
pins on both sides of the platform bar.
8.Slide the platform bar from the fixed end on the
other side of the platform so that the slider is moved
to the platform rail slot, where the belt of the fixed
platform bar is slowly raised to a certain height.
Carefully lift the platform away from the machine and
place it on a device that can be used as a support.
Caution! Before removing the platform, note
the mounting position of the wear pad on the
platform so that they can be assembled in the correct
position when assembled.
