Figure 3 Filters for HMP63 and HMP113
6 Plastic membrane filter, pore size 0.2 µm
7 Plastic grid filter for (portable use only, fastest response time)
8 Porous PTFE filter, pore size 8 µm
9 Stainless steel sintered filter, pore size 38 µm
All filters are 12 mm in diameter.
2.3
Installation accessories (optional)
For item codes, see Spare parts and accessories (page 83).
2.3.1 Probe mounting clamp
The optional mounting clamp makes it easy to install the probe on the wall of the
measurement environment. The probe can be detached for calibration simply by loosening the
lower screw.
Figure 4 Probe mounting clamp in use
The probe mounting clamp is delivered in 2 parts that must be connected when it is used:
HMP60 and HMP110 Series User Guide M211060EN-J
14
