max. 3 [0.12]
Figure 20 Installation with plastic M12 nuts
9.5.2 HMP63 and HMP113 dimensions
79.5 [3.13]
24.5 [0.96]
3.5
[0.14]
Ø 14
[0.55]
Ø 12
[0.47]
Figure 21 HMP63 and HMP113 dimensions in mm [in]
68 [2.68]
M15x1
Ø 21.6 [0.85]
Figure 22 HMP63 and HMP113 with plastic locking bushing
HMP60 and HMP110 Series User Guide M211060EN-J
82
