GUID-E15B10AB-FDBF-434D-8E9B-382DBE0F78B6
1. Total fuel consumption
3.10.2.9 Rear lower links' position view
The view shows the position of the rear lower links .
GUID-D2673DEE-E150-401F-8439-8E61709A3C22
1. Position of the rear lower links
The display shows the symbol and the position of the rear lower links on a
percentage scale 0-100:
• 0 = The lower links are in the lowest position.
• 50 = The lower links are in the middle position.
• 100 = The lower links are in the top position.
NOTE: The percentage value may not achieve the limit values (0 or 100) even if
the linkage is functioning correctly.
3.10.2.10 Gearbox temperature view
