GUID-EB6EAC00-A5A5-4A6A-9659-AEA81CEBBFD8

1. 250 mm, 2000 kg

2. 400 mm, 1200 kg

3. 550 mm, 500 kg

4. 245 mm

5. Drawbar pin Ø31.5 mm

6. 21° to both sides

6.14.6.5 Towing device frames

NOTE: The loadings are applicable to all tires.

D-value / Max permissible vertical loading for a trailer

hitch with all jaws

89.3 kN / 2000 kg

D-value / Towing device frame with piton-fix pin, max

permissible vertical loading

89.3 kN / 3000 kg

D-value / Towing device frame with K80 ball hitch,

max permissible vertical loading

89.3 kN / 4000 kg

D-value / Towing device frame drawbar, max

permissible vertical loading

78.5 kN / 1200 kg (400 mm), 500 kg (550 mm)

Automatic jaw, main pin diameter 31.5 mm (ISO 6489-2, B) / 38 mm (ISO 6489-2, C)

Table continued on next page

6. Technical specifications

- 402 -

Valtra T214 User Manual
