• defrost is connected
• LO mode is connected
• a different fan speed is selected manually
3.6.4.1 Automatic air conditioning control panel and display
Control panel
GUID-DDF9F4A0-689E-45E8-B4AA-5455ED35A00D
1. Fan speed control knob (selection OFF/Auto/Manual)
2. Defrost
3. Display
4. Air conditioning ON/OFF
5. Temperature control knob
6. Additional heater fan speed decrease (selection Manual/OFF/Auto)
7. Additional heater fan speed increase (selection ON/Manual)
Display
GUID-F20FB364-0A39-4A5B-BE19-605EA501B52F
1. Automatic mode
2. Fan speed
3. Set temperature
4. Additional heater
5. ECO mode
Indicator
Indication
Displayed when the automatic fan speed and the AC compressor are on.
Displays the fan speed.
Table continued on next page
3. Operation
- 91 -
