3.14.1 Controlling the auxiliary hydraulics rear valves
You can control the auxiliary hydraulics rear valves with the control levers.
GUID-4D21058D-468A-4484-9D51-AA99ADF947F2
1. Control lever for the auxiliary hydraulics rear valve 1
2. Control lever for the auxiliary hydraulics rear valve 2
3. Control lever for the auxiliary hydraulics rear valve 3 (optional)
4. Control lever for the auxiliary hydraulics rear valve 4 (optional)
5. Valve mode selector (optional)
6. Kick-out mode (optional)
7. Spring return mode (optional)
8. Position lock mode (optional)
• To use the lifting function, pull the control lever for the auxiliary hydraulics
rear valve backwards.
• To use the lowering function, push the control lever for the auxiliary
hydraulics rear valve forward.
3. Operation
- 191 -
