Pax-i3D Smart(PHT-30LFO) Installation Manual
80
6 Setting up PC
6.4
Connecting the Cables to PC
Always check the cable condition visually. Surprisingly, unexpected errors
affecting image acquisition arise from the bad cable or its bad contact condition.
Connect the regular cables for PC: keyboard, mouse, and video in advance.
The following gures and descriptions are based on the PC model Z420 from HP.
1
. Connect the ber optic cable (Part No.: 21)
2.
Insert the 3D viewer USB key(Part No.:1) into
a USB port.
To Next Page
