Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
108
Installing Rectifier Modules into Spec. No. 588705500 Module Mounting Assemblies
Rectifier modules can be inserted or removed with power applied (hot swappable).
NOTE! The rectifier module locks into the module mounting assembly through a latch located on the
underside of the module. The latch and module handle are interactive. Push the handle into the
module’s front panel, and the latch will pop out from the module bottom. Click the handle to pop it out
from the module’s front panel, and the latch will retract back into the module. The latch mechanism is
shown in Figure 76 .
WARNING! To prevent damage to the latching mechanism, ensure the handle is in the open position
when installing or removing a module. NEVER hold the handle in the closed position when installing a
module into a shelf.
NOTE! 588705500 List 04 and List 05 Rectifier Mounting Assemblies Only (3-Phase Input): One
three-phase input feeds the three rectifier modules on the left-hand side of the shelf. The second three-
phase input feeds the modules on the right-hand side. To maintain phase balance, install rectifier
modules in groups of three; that is, fill all three mounting positions on the left and/or all three on the
right.
Procedure
1. Unpack the rectifier modules.
2. If present, remove blank cover panels from the module mounting positions into which modules are to be
installed.
3. Place the module into an unoccupied mounting slot without sliding it in completely.
4. Click the module handle in order to pop it forwards out of the module’s front panel (this will also retract
the latch mechanism located on the underside of the module).
5. Push the module completely into the shelf.
6. Push the handle into the front panel of the module. This will make the latch lock the module securely to
the shelf.
7. Repeat the above steps for each module being installed in the system.
8. After the modules are physically installed in the mounting shelf(s), they are ready for operation
immediately after power is supplied to them.
