Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
Connecting Converter Output Cables 582127000 List 60
NOTE!
These connections are factory made for shelves factory installed. The connection must be
made if a field expansion shelf is installed.
Refer to Connecting Converter Output Cables 582127000 List 60 in the MAKING ELECTRICAL CONNECTIONS
section of the Installation Instructions (IM582127000) for complete procedures.
Refer to Figure 42 to connect the converter output cables between the dual voltage distribution panel and the
rectifier/converter module mounting assembly Spec. No. 588705300.
