Vertiv NetSure 7100 Series User Manual

Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
98
Load Connections to GMT Distribution Fuse Block
Figure 65: Optional Bullet Nose 6-Position GMT Distribution Fuse Block
Wire Size Capacity: 26-14
AWG.
Recommended
Torque: 4.5 in-lbs.
35
A maximum capacity per block.
Maximum GMT fuse size is 15A.
Wire Size Capacity: 26-14 AWG.
Recommended Torque: 4.5 in-lbs.
35A maximum capacity per block.
Maximum GMT fuse size is 15A.
Load Return Leads
-48VDC Load Leads
1/4-20 Hardware.
Torque to 75 in-lbs.
Part of P/N 549017
Part of P/N 549017
Load Return Leads
-48VDC Load Leads
P/N 550224
