Installing the Rectifier and Converter Modules into Spec. No. 588705300 Module
Mounting Assemblies
Rectifier and converter modules can be inserted or removed with power applied (hot swappable).
Rectifiers modules can be installed in any mounting position of each module mounting assembly. Converters
modules can be installed in any of the three far right mounting positions of each module mounting assembly
(as viewed from the front). See Figure 77.
NOTE! Each rectifier and converter module locks into the module mounting assembly by means of a
latch located on the bottom of the module. The latch and module handle are interactive. Pushing the
handle up into the module’s front panel causes the latch to extend to the locking position; pulling the
handle down out from the module’s front panel causes the latch to retract. See Figure 77 .
WARNING! To prevent damage to the latching mechanism, ensure the handle is in the open position
when installing or removing a module. NEVER hold the handle in the closed position when installing a
module into a shelf.
Procedure
1. Unpack the modules.
2. Note the model number located on the front of each module. Model numbers starting with the letter “R”
are rectifier modules. Model numbers starting with the letter “C” are converter modules.
3. Place the module into an unoccupied mounting position without sliding it in completely. Rectifiers
modules can be installed in any mounting position of each module mounting assembly. Converters
modules can be installed in any of the three far right mounting positions of each module mounting
assembly (as viewed from the front). See Figure 77.
4. Loosen the captive screw on the module’s handle. Pull the handle down out from the module’s front
panel (this will also retract the latch mechanism). See Figure 77.
5. Push the module completely into the shelf.
6. Push the handle up into the module’s front panel. This will lock the module securely to the shelf.
Tighten the captive screw on the handle.
7. Repeat the above steps for each module being installed in the system.
8. After the modules are physically installed in the mounting shelf(s), they are ready for operation
immediately after power is supplied to them.
