Vertiv | NetSure 7100 Series Quick Start Guide (QS582127000) | Rev. T
Make Nominal 400 Volts DC Input and Equipment Grounding Connections (if equipped)
Refer to Nominal 400 Volts DC Input and Equipment Grounding Connections (if equipped) in the MAKING
ELECTRICAL CONNECTIONS section of the Installation Instructions (IM582127000) for a complete procedure.
NOTE THAT THIS SYSTEM MAY BE EQUIPPED WITH AC OR DC INPUTS. THESE PROCEDURES
APPLY TO SYSTEMS WITH DC INPUTS. SPECIFICALLY, THESE PROCEDURES APPLY TO THE
FOLLOWING EQUIPMENT:
• 582127000 List 45, 46, 47
• 588705000 List 41, 42
DC Input Termination Assemblies
The available DC input options for this system are:
• The system can be equipped with a DC input termination assembly which provides a separate DC input
connection for each converter position (582127000 List 45).
• The system can be equipped with a DC input termination assembly which provides a separate DC input
connection for every two (2) converter positions (582127000 List 46).
• The system can be equipped with a DC input termination assembly which provides a separate DC input
connection for every three (3) converter positions (582127000 List 47).
Direct DC Input Connections to the Module Mounting Assemblies
• The system can be equipped with module mounting assemblies that contain DC input terminal blocks
which provide a separate DC input connection for each converter position (588705000 List 41).
• The system can be equipped with module mounting assemblies that contain DC input terminal blocks
which provide a separate DC input connection for every two (2) converter positions (588705000 List
42).
Connections to DC Input Termination Assemblies (582127000 List 45, 46, and 47)
Refer to Figure 25, Figure 26, or Figure 27.
NOTE!
Terminal blocks for a system with maximum possible converter shelves shown. Your system
may have less terminal blocks then shown.
