Vimar Eikon Instruction Handbook

62 - ENGLISH
9.4.1
Activate the IrDA port on the smart card
reader/programmer as described in sec-
tions 8.1 or 9.3 (depending on the reader
operating mode)
9.4.2
Connect the 16474 serial connector to
the PC or PDA.
9.4.3
Insert the flat connector into the smart
card reader / programmer (with the con-
tacts facing up).
Remember to select the correct serial
port on the PC or PDA.
As an alternative to the IrDA interface, it is possible to use
a smart card 16474 serial communication link between the
smart card reader/programmer and the interface device (PC
or PDA).
16474
9.4
Connection via a smart card for
16474 serial link
