ENGLISH - 19
The “Synchronise readers with MASTER smart card” pro-
cedure programs several readers to work with the same
MASTER smart card, the same address and the same
MASTER code.
1 2 3 4
ON
4.3.1
Place dip-switch 2 on the reader being
synchronised in the ON position
The LED lights up yellow.
4.3.3
Insert into the reader a MASTER smart
card programmed by the synchronising
reader.
Synchronising
card
Synchronising
card
4.3.2
Press the front button within 15 sec-
onds. The LED turns green.
Warning!
If the button is not pressed within 15
seconds, the LED turns green and the
system switches to the “Initialise reader
and program MASTER smart cards”
procedure.
To exit the procedure, place dip-switch 2
in the OFF position.
Repeat the procedure from step 4.3.1.
4.3
Synchronising readers with
MASTER smart cards
Synchronising a non-initialised reader
