26 - ENGLISH
If the smart card is not recognised, the
LED blinks red. Remove the incorrect
smart card and insert the correct one.
5.2.3
When the LED turns off, the smart card
has been recognised.
5.2.4
Remove the smart card.
The LED turns green, waiting for other
smart cards to program.
5.2
Reprogramming the reader code
and SLAVE smart cards
This procedure changes the code assigned to the address
of the reader/programmer, and saves it to the smart card.
5.2.1
Place dip-switch 1 in the ON position.
The LED lights up yellow.
1 2 3
4 5 6
7 8
ON
Card
already
programmed
Card
already
programmed
5.2.2
When the LED turns red (after about 15
seconds), insert the smart card with the
code currently in use.
