22 - ENGLISH
4.4 Initialising the reader and pro-
gramming or reprogramming
SLAVE smart cards
This procedure generates a SLAVE code in the memory of
the reader/programmer being initialised, and copies it to the
desired smart cards.
Each time the “Initialise reader and program SLAVE
smart card” procedure is invoked, a different code will
be generated.
To carry out this procedure it is necessary to have the
MASTER smart card (see paragraph 4.1).
4.4.1
Press the front button.
The LED blinks in the sequence red-off-
green.
4.3.15
To exit the procedure, place dip-switch 2 in
the OFF position. The LED switches off.
1 2 3 4
6
7 8
ON
4.3.14
Remove the smart card.
The LED turns green again.
