Vision MAX Pro User Manual

Vision Max Pro User Manual80
© 2015 Vision Engraving Systems
4.1.1.1 Example Job 1 - Diamond Drag
In this first example, Diamond Drag engraving will be performed on a 3" x 2" plate. The material used for
this example application is black painted aluminum.
Starting with a new file in Vision 9 software, the first step is to adjust the plate size to match the plate to
be engraved.
Click on the Plate Size icon.
