Service procedures - engine Group 21
20
Service procedures
The engine must always be washed before repairs are started
Engine fixture, attaching
Special tools: 998 6485, 999 6962
1
Remove the oil cooler as shown in ”oil cooler, replacing”.
2
Remove the spacer plate (four screws).
3
Remove the bypass filter and bracket (four screws).
4
Cover the holes with rags or equivalent to prevent dirt or for-
eign matter from entering the engine.
5
Mount the engine fixture on the engine.
6
Lift the engine in place and secure it with screws and nuts in
the holes on the assembly stand (four).
